We build our wireless steering wheel kits with the help of a number of different companies. The end result is a super modern and easy to use system to have all vital driver controls at the drivers fingertips.
Features:
- Custom built carbon steering wheel plates to most wheel types
- Professionally 3D Printed Rear Enclosure
- Numerous Switch Layout configurations available
- Wheel mounted paddles for paddleshift available
- Rotary switches for Launch/Traction/Boost etc available
- Optional CAN Interface
Kit Includes:
- Carbon Wheel Plate and Rear Enclosure with transmitter built to customers specification.
- Wireless Receiver
- Connector Housing and Terminals to suit Wireless Receiver
- USB Configuration Cable
- Free Configuration Software
- Optional 120Ohm CAN Termination Resistor
- Optional CAN Preset
Need a matching Steering Wheel, Boss Kit and Quick Release? Check out our Steering Wheels here: https://www.ptmotorsportelectrics.com/collections/steering-wheels
and accessories here: https://www.ptmotorsportelectrics.com/collections/steering-wheel-accessories
Wireless Module Types:
8 Channel Relay Kit:
- Control up to 8 channels with endless re-configuration possibilities, using the included free programming software.
- Includes internal relays rated to 15A at 12V and can be used for high- or low-side switching of loads.
- Optional CAN Interface output for seamless PDM/ECU or Dash Display integration. We can supply the kit with many different CAN Presets to suit Ecumaster, Link ECU, MaxxECU, Haltech and more.
- Choose any combination of smart headlight, smart indicator and IVA fog light modes or momentary and latching behaviour for each channel.
- The 8 Relay Receiver measures 121 x 66 x 40mm and weighs 385g.
- At a tiny 54 x 38 x 23mm, the Transmitter weighs just 61g including the battery!
10 Channel Solid State Kit:
- Full solid-state low-side switching of up to eight, 600mA loads, such as standard automotive relays, with built-in short circuit and overcurrent protection and endless re-configuration possibilities, using the included free programming software.
- Two analogue channels for wireless potentiometer control such as Launch, Traction, Boost Control and many more
- Optional CAN Interface output for seamless PDM/ECU or Dash Display integration. We can supply the kit with many different CAN Presets to suit Ecumaster, Link ECU, MaxxECU, Haltech and more.
- Includes a rainlight function, perfect for racing with dual solid light and 4Hz flashing hazard modes, and Flash-to-Pass to give a 2-second 4Hz headlight flash.
- Choose any combination of smart headlight, smart indicator, IVA fog light and rainlight modes or momentary and latching behaviour for each solid state channel.
- The Receiver measures 86 x 55 x 35mm and weighs 285g.
- At a tiny 54 x 38 x 23mm, the Transmitter weighs just 61g including the battery!
10 Channel CAN Only Kit:
- Full low-side switching of up to eight, 600mA loads all via CAN with endless re-configuration possibilities, using the included free programming software.
- Two analogue channels for wireless potentiometer control such as Launch, Traction, Boost Control and many more
- Seamless PDM/ECU or Dash Display integration. We can supply the kit with many different CAN Presets to suit Ecumaster, Link ECU, MaxxECU, Haltech and more.
- Includes a rainlight function, perfect for racing with dual solid light and 4Hz flashing hazard modes, and Flash-to-Pass to give a 2-second 4Hz headlight flash.
- Choose any combination of smart headlight, smart indicator, IVA fog light and rainlight modes or momentary and latching behaviour for each solid state channel.
- The Receiver measures 86 x 55 x 35mm and weighs 112g.
- At a tiny 54 x 38 x 23mm, the Transmitter weighs just 61g including the battery!
All kits are made to order with a minimum 4 - 6 week lead time. Please contact us prior to purchasing with any custom requirement you may have.
